Welded Wire Mesh
Hot dipped galvanized after welding Hot dipped galvanized before welding
product description
Hot dipped galvanized after welding
Hot dipped galvanized before welding
Pvc coated with galvnized core
Super adhesive pvc coated with galvanized core
| Mesh mm | Wire dia mm | Width cm | Length m |
| 6x6 | 0.60 | 100 | 25 |
| 6x6 | 0.80 | 100 | 25 |
| 8x8 | 0.80 | 100 | 25 |
| 10x10 | 0.80 | 100 | 25 |
| 13x13 | 0.65 | 100 | 25 |
| 13x13 | 0.80 | 100 | 25 |
| 13x13 | 1.00 | 100 | 25 |
| 13x13 | 1.20 | 100 | 25 |
| 16x16 | 1.20 | 100 | 25 |
| 19x19 | 1.00 | 100 | 25 |
| 19x19 | 1.40 | 100 | 25 |
| 25x25 | 1.00 | 100 | 25 |
| 25x25 | 1.60 | 100 | 25 |
| 13x13 | 0.8/1.2 | 100 | 25 |
| 19x19 | 0.8/1.2 | 100 | 25 |
| 25x25 | 1.0/1.4 | 100 | 25 |
MINI ROLLS
| Mesh mm | Wire dia mm | Width cm | Length m |
| 13x13 | 0.65 | 50 | 5 |
| 13x13 | 0.65 | 100 | 5 |
| 19x19 | 1.05 | 50 | 5 |
| 19x19 | 1.05 | 100 | 5 |
| 13x13 | 1.00 | 50 | 5 |
| 13x13 | 1.00 | 100 | 5 |
| 19x19 | 1.40 | 50 | 5 |
| 19x19 | 1.40 | 100 | 5 |
Standard roll is 1m high by 25m long.
Each roll packed in plastic shrink foil with label, then onto pallet.
Mini rolls can be packed into carton or in bundle.
