CLEAR VIEW HIGH
High security
Efficient deterrence
Long lifetime
Easy installation
Complete system
product description
DESCRIPTION:
CLEAR VIEW HIGH is welded mesh panel with 1/2” = 12.7mm axis distance of horizontal wires. The small mesh opening make it impossible to climb or use any tool to cut.
FINISH:
| Galvanized and powder coated | Zinc Aluminum and powder coated | Galvanized and plastic dip coated |
  |  |  |
| Mesh mm | Vertical Wire dia mm | Horizontal Wire Dia mm | Height mm | V bends | Width mm | |
| 76.2x12.7 | 4 | 3 | 1200 | 2 | 2515 | 3050 |
| 76.2x12.7 | 4 | 3 | 1800 | 4 | 2515 | 3050 |
| 76.2x12.7 | 4 | 3 | 2000 | 4 | 2515 | 3050 |
| 76.2x12.7 | 4 | 3 | 2200 | 4 | 2515 | 3050 |
| 76.2x12.7 | 4 | 3 | 2400 | 4 | 2515 | 3050 |
